Clutch/Brake Control MPN:CBC-150-2

This C-Face clutch and brake control features Autogaps™ technology, which allows it to automatically adjust for wear, requiring no lubrication or maintenance. The packaged NEMA C-face clutch/brake module offers high-performance starting and stopping of loads, with the motor running, in an easy-to-install package. Mount to NEMA C-face motor, or between motor and reducer. Power on engagement of the brake and clutch. Note: Brake is not intended for accurate positioning applications or vertical holding applications, such as vertical conveyors or hoists.

Technical Specifications

• Item Clutch/Brake Control
• Input Voltage 220/240 V AC
• Voltage Output 90V DC
• Hz 60/50
• Ambient (C) -29 Degrees to 45 Degrees C
• Mounts On the Standard Module Conduit Box
• Status Indicator Green LED Indicates Power to Clutch, Red LED Indicates Power to Brake
• Function Convert AC Voltage into DC Voltage
• Length (In.) 3 1/3 in
• Width (In.) 2 3/16 in
• Height (In.) 9/16 in
• Agency Compliance CE and UL
• For Use With All Series 90 V Clutch/Brakes

Manufacturer Details

• Manufacturer: Warner Electric
• Condensed Mfg Number: CBC1502
• MPN: CBC-150-2

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8537109090
• GDS Category Name: Brake and Clutch Accessories
• GDS Family Name: Brakes and Clutches
• GDS Segment Name: Power Transmission
• UNSPSC: 26111909
• UNSPSC Class ID: 19
• UNSPSC Commodity Name: Clutches
• UNSPSC Commodity ID: 09
• UNSPSC Commodity Name: Electrical clutches
• UNSPSC Family ID: 11
• UNSPSC Family Name: Batteries and generators and kinetic power transmission
• UNSPSC Segment ID: 26
• UNSPSC Segment Name: Power Generation and Distribution Machinery and Accessories

Shipping Details

• Not For Sale In: HI AK PR
