Axial Fan Square 12 H 630 CFM MPN:FBF1010115V
Axial Fan Square 12 H 630 CFM
Standard square axial fans are used in dry locations to cool equipment within an enclosure. These equipment-cooling fans have a square housing that can mount over a round cutout or fit into a square cutout for installation.Square compact axial fans have a square-shaped housing that can span a round cutout or fit into a square cutout for cooling equipment within an enclosure. These equipment-cooling fans require minimal space for installation and are typically installed where there's full access for mounting them against the interior of an enclosure. They have mounting holes at each corner for securing them to a wall or panel.
Technical Specifications
- Item Standard Square Axial Fan
- Fan Shape Square
- Height 11 5/8 in
- Depth 4 13/64 in
- Width 11 5/8 in
- CFM @ 0.000-In. SP 630
- Voltage 115V AC
- Hz 60/50
- Amps 0.21
- Electrical Connection - Fans Terminals
- Sound Level 62
- IP Rating IP43
- Mounting Position Vertical
- Bearing Type Ball
- RPM 3000
- Motor Insulation Class A
- Thermal Protection Impedance
- Max. Ambient Temp. 104 Degrees F
- Blade Material PA Plastic
- Housing Material PBT Plastic
- Requires Hard Wiring
- Standards cULus
- Environmental Applications Equipment Cooling
Manufacturer Details
- Manufacturer: Wiegmann
- Condensed Mfg Number: FBF1010115V
- MPN: FBF1010115V
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MT
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8414596590
- GDS Category Name: Axial Fans
- GDS Family Name: Cooling Fans and Air Circulators
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 40101604
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Air circulation and parts and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Fans
- UNSPSC Family ID: 10
- UNSPSC Family Name: Heating and ventilation and air circulation
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:43am UTC
Category: Cooling Fans and Air Circulators
